Boiler Tube Expanders
‘T-114’ Series (Flare) - 4 Plain Rollers & 2 Flare Rollers
Ÿ Multi purpose expander Ÿ Boiler Tubes
Ÿ Popular choice for expanding & flaring Ÿ Water Wall
Ÿ Economizer
Ÿ Riser & Air Heater Tubes
Min Max. TUBE EXPANDER MODEL
TUBE SIZE I.D. Expansion
Tool of Tube Sheet Thickness Range
Enters Tool 1/2” 3/4” 1.1/8” 1.5/8” 2.1/8”
O.D THK O.D. THK to to to to to
inch bwg inch bwg mm inch mm inch 7/8” 1.1/8” 1.5/8” 2.1/8” 2.5/8”
Tube Sheet Thickness Codes > 2 3 4 5 6
4 -5 1.3/4 11 - 13 36.7 1.444 43.1 1.696 - T14172 T14174 T14176 T14178
6 - 7 1.3/4 14 - 16 38.3 1.507 44.6 1.755 - T14182 T14184 T14186 T14188
2 7 -8 39.9 1.570 46.4 1.826 T14191 T14192 T14194 T14196 T14198
9 -10 2.1/4 13 41.5 1.633 48.0 1.889 T14201 T14202 T14204 T14206 T14208
11-13 2.1/4 4 - 5 43.1 1.696 49.6 1.952 T14211 T14212 T14214 T14216 T14218
2 2.1/4 6 - 8 45.5 1.791 52.6 2.070 - T14222 T14224 T14226 T14228
3 - 4 2.1/4 9 - 11 47.1 1.856 54.2 2.133 - T14232 T14234 T14236 T14238
2. ½ 4 - 6 2.1/4 12 - 15 49.0 1.929 57.3 2.255 - T14242 T14244 T14246 T14248
7 - 10 2.3/4 2 - 3 51.9 2.043 60.5 2.381 - T14252 T14254 T14256 T14258
11 -13 2.3/4 4 - 5 55.1 2.169 63.7 2.507 T14261 T14262 T14264 T14266 T14268
1 - 3 2.3/4 6 - 10 57.4 2.259 66.6 2.622 - T14272 T14274 T14276 T14278
3 4 - 6 2.3/4 11 - 15 60.6 2.385 70.0 2.755 - T14282 T14284 T14286 T14288
7 -11 3.1/4 1 - 4 63.8 2.511 73.9 2.909 - T14292 T14294 T14296 T14298
10 -12 3.1/4 4 - 7 66.9 2.635 77.3 3.043 T14301 T14302 T14304 T14306 T14308
1 - 4 3.1/4 7 -11 70.1 2.759 80.1 3.153 - T14312 T14314 T14316 T14318
3. ½ 4 - 7 3.1/4 10 -15 73.0 2.874 83.4 3.283 - T14322 T14324 T14326 T14328
7 -11 3.3/4 2 - 3 76.2 3.000 86.8 3.417 - T14332 T14334 T14336 T14338
10 -12 3.3/4 4 -5 79.3 3.122 89.8 3.535 - T14342 T14344 T14346 T14348
1 - 4 3.3/4 6 -10 82.5 3.248 93.0 3.661 - T14352 T14354 T14356 T14358
4 4 - 7 3.3/4 11 -15 85.7 3.374 96.0 3.779 - T14362 T14364 T14366 T14368
7-11 4.1/4 2 - 3 88.9 3.500 98.6 3.881 - T14372 T14374 T14376 T14378
8 - 12 4.1/4 3 - 5 90.5 3.562 102.3 4.027 - T14382 T14384 T14386 T14388
1 - 4 4.1/4 6 -9 95.2 3.748 104.7 4.122 - T14392 T14394 T14396 T14398
4.1/2 3 - 8 4.1/4 10 -13 98.4 3.874 110.3 4.342 - T14402 T14404 T14406 T14408
6 -12 101.6 4.000 113.5 4.468 - T14412 T14414 T14416 T14418
